Deploying MySQL and Microservice on AWS EKS with EBS for HealthSync

MySQL and User Management Microservice on AWS EKS with Amazon

AMJ Cloud Technologies delivered a secure, scalable MySQL database and user management microservice with persistent Amazon Elastic Block Store (EBS) storage in an Amazon Elastic Kubernetes Service (EKS) cluster for HealthSync Innovations, a healthcare startup. By leveraging the EBS CSI Driver, Kubernetes Storage Classes, Persistent Volume Claims (PVCs), and a microservices architecture, we provided an automated, compliant, and reliable solution for their patient data management platform, addressing challenges with manual storage setups, data persistence, and microservice integration.

Situation

HealthSync Innovations, a healthcare startup focused on patient data management, required a robust MySQL database and a user management microservice to handle authentication and profile data for their cloud-based platform. Their legacy systems relied on manual configurations, risking data loss, scalability limitations, and non-compliance with healthcare data security standards. AMJ Cloud Technologies was engaged to deploy a cloud-native solution on AWS EKS, integrating a MySQL database with persistent EBS storage and a user management microservice to ensure seamless operation and regulatory compliance.

Task

The objective was to implement a Kubernetes-based infrastructure with:

• A Storage Class for dynamic provisioning of encrypted EBS volumes.
• A Persistent Volume Claim (PVC) for 4Gi of secure MySQL storage.
• A ConfigMap to initialize the patientdb database schema.
• A MySQL Deployment with persistent, encrypted storage and a ClusterIP Service.
• A User Management Microservice Deployment connected to MySQL, with a NodePort Service for external access.
• Automated deployment using Kubernetes manifests and API validation with Postman.
• Completion within three weeks to meet HealthSync’s product launch timeline.

Action

Our DevOps team executed the following steps, adhering to best practices for security, scalability, and microservices:

Setting Up the EBS CSI Driver

• Deployed the EBS CSI Driver for dynamic EBS volume provisioning:

  kubectl apply -k "github.com/kubernetes-sigs/aws-ebs-csi-driver/deploy/kubernetes/overlays/stable/?ref=master"


• Created an IAM policy with least-privilege permissions for volume management and attached it to the EKS worker node role.

Defining Kubernetes Manifests

• Storage Class Example (01-storage-class.yml):

  apiVersion: storage.k8s.io/v1
  kind: StorageClass
  metadata:
    name: ebs-sc
  provisioner: ebs.csi.aws.com
  volumeBindingMode: WaitForFirstConsumer
  parameters:
    type: gp3
    encrypted: "true"


• Persistent Volume Claim (02-persistent-volume-claim.yml): Requested 4Gi of encrypted storage.
• ConfigMap (03-PatientDB-ConfigMap.yml): Initialized the patientdb schema.
• MySQL Deployment (04-mysql-deployment.yml): Configured with persistent storage and secure credentials.
• MySQL Service (05-mysql-clusterip-service.yml): Used clusterIP: None for direct pod access.
• User Management Microservice Example (06-UserManagementMicroservice-Deployment.yml):

  apiVersion: apps/v1
  kind: Deployment
  metadata:
    name: usermgmt-microservice
  spec:
    replicas: 1
    selector:
      matchLabels:
        app: usermgmt-restapp
    template:
      spec:
        containers:
          - name: usermgmt-restapp
            image: stacksimplify/kube-usermanagement-microservice:1.0.0
            env:
              - name: DB_HOSTNAME
                value: "mysql"
              - name: DB_NAME
                value: "patientdb"


• User Management Service Example (07-UserManagement-Service.yml):

  apiVersion: v1
  kind: Service
  metadata:
    name: usermgmt-restapp-service
  spec:
    type: NodePort
    ports:
      - port: 8095
        nodePort: 31231
    selector:
      app: usermgmt-restapp


Applying and Verifying the Deployment

• Applied all manifests:

  kubectl apply -f kube-manifests/


• Verified resources:

  kubectl get sc,pvc,pv
  kubectl get pods
  kubectl get svc


• Tested MySQL and microservice connectivity:

  kubectl run -it --rm --image=mysql:5.6 --restart=Never mysql-client -- mysql -h mysql -u root -pdbpassword11


Testing the User Management Microservice

• Retrieved the EKS worker node public IP:

  kubectl get nodes -o wide


• Tested the health status API:

  curl http://<EKS-WorkerNode-Public-IP>:31231/usermgmt/health-status


• Used Postman with the imported collection (example snippet):

  {
    "info": {
      "name": "AWS-EKS-Masterclass-Microservices",
      "schema": "https://schema.getpostman.com/json/collection/v2.1.0/collection.json"
    },
    "item": [
      {
        "name": "UserManagement-HealthStatus",
        "request": {
          "method": "GET",
          "url": "{{url}}/usermgmt/health-status"
        }
      },
      {
        "name": "UserManagement-CreateUser",
        "request": {
          "method": "POST",
          "body": {
            "mode": "raw",
            "raw": "{\"username\": \"patient1\", \"email\": \"patient1@healthsync.com\", \"role\": \"ROLE_PATIENT\", \"enabled\": true}"
          }
        }
      }
    ]
  }


• Configured Postman environment: url=http://<EKS-WorkerNode-Public-IP>:31231.

Cleanup

• Removed all resources:

  kubectl delete -f kube-manifests/


Result

AMJ Cloud Technologies delivered a robust solution for HealthSync Innovations:

• Deployment Automation: Fully automated MySQL and microservice provisioning, reducing setup time from weeks to hours.
• Data Persistence: 100% reliable storage for patient data with encrypted EBS volumes.
• Scalability: Supported up to 50,000 patient records with dynamic provisioning and microservices.
• Compliance: Ensured healthcare data security with encrypted storage and secure access.

Technologies Used

• AWS EKS
• Amazon EBS
• EBS CSI Driver
• Kubernetes Storage Classes
• MySQL
• Microservices

Best Practices Followed

• Security: Encrypted EBS volumes and least-privilege IAM policies for healthcare compliance.
• Automation: Kubernetes manifests and Postman for repeatable deployments and testing.
• Scalability: Dynamic provisioning and microservices for growth.
• Reliability: Noted initContainers as a future enhancement to prevent microservice restarts.
• Monitoring: Recommended AWS CloudWatch for EBS and pod health.
